Name: Arsenal-5030A luggage scanner x ray baggage scanning machine
SKU: 654613612-1-2-1-1-1-1-1-1-1-1-1-3-1
Availability: InStock

Product features

Original Hamamatsu detectors, image quality, Omron electrical components.Enhance the overall quality
Global leading parameters: the inspection report issued by the Ministry of Public Security, shows that each parameter is ahead of other products, more details in the inspection report.
Energy-saving design: The machine can sense objects automatically,if there is luggage on the machine will be operating, if there is no luggage,it’ll be quiet. (Optional)
A key shutdown control: simply rotate the key when clicking shutdown,safe shutdown automaticly ,reduce equipment failure.
Environmental-friendly Design: lead shade with protective film, prevent lead from hand contact, avoid lead pollution.
Dynamic screen switching: when it is stationary screen it can be switched and when it is dynamic it also can switch freely.

Function

Original Hamamatsu detectors, image quality, Omron electrical components.Enhance the overall quality
Global leading parameters: the inspection report issued by the Ministry of Public Security, shows that each parameter is ahead of other products, more details in the inspection report.
Energy-saving design: The machine can sense objects automatically,if there is luggage on the machine will be operating, if there is no luggage,it’ll be quiet. (Optional)
A key shutdown control: simply rotate the key when clicking shutdown,safe shutdown automaticly ,reduce equipment failure.
Environmental-friendly Design: lead shade with protective film, prevent lead from hand contact, avoid lead pollution.
Dynamic screen switching: when it is stationary screen it can be switched and when it is dynamic it also can switch freely.

Specifications

X-ray Generator
Ray Beam direction	Bottom-illuminated
Tube current	0.4~0.5mA(adjustable)
Tube voltage	100-160 kV(adjustable)
Ray beam divergence angle	60°
The cooling / work cycle	Sealed oil cooling / 100%
Image Processing System
X-ray sensor	L-shaped photodiode array detector (C), 24bit depth
Monitor	high resolution 19 inch LCD SamSung monitor
Color image display	24-bit true color display
Edge Enhancement	the outline of objects will be more clear
Super Image Enhancement	the details of the image are more clear
High penetration display	improve image contrast in bright areas, so the easy penetrating area will be more clear
Low penetration display	improve image contrast in dark areas, so the difficult penetrating area will be more clear
Magnifier	local amplification function
Brighten / darken	Increase/ decrease image brightness
Image pull back / front pull	Show the top 20 images, and the current image can be any image processing
Image Restoration	Restored to its original state
Image Storage	Real-time save any image, any image can be processed arbitrarily ,continuous work to save
Environmental conditions
Operating temperature / humidity	0℃~45℃/20%~95% (No condensation)
Storage temperature / humidity	-20℃~60℃/20%~95% (No condensation)
Operating Voltage	90V~250V 50/60Hz
Power consumption	1.0KW(maximum)
Noise level	<55dB (A)

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Model NO:	Arsenal-XR5030	Application:	Security Check, Industrial
Alarm Form:	Display Alarm	Conveyor Speed:	0.22m/S
Package:	Carton Boxes or According Customer′s Need	Portable:	Non Portable
Customized:	Non-Customized	Noise:	Less Than 55dB(a)

Certification:	CE, ISO, FCC RoHS	Type:	Conveying X-ray Detector
Operating System:	Windowsxp	Nw / Gw:	290 Kg / 360 Kg
