CEIA HI-PE Multi Zone

Specifications

Key features

• Accurate Detection of magnetic, non-magnetic and mixed-alloy metal weapons
• Wide range of threat detection from guns to ½ cutter blade
• High Discrimination and Throughput
• Exceptional Immunity to external interferences
• High precision bidirectional counter with automatic rescreening compensation (option)
• Random alarm capability programmable from 0% to 100% (option)
• Powered by safe low voltage DC
• Standard Interfaces: RS-232, Infrared
• Other available interfaces: Ethernet, USB

Quality

• Continuous self diagnostic system
• Proven reliability
• No periodic re-calibration and preventive maintenance required
• No scheduled maintenance
• Fully digital design

Walk-through gate structure

• State-of-the-art, robust and washable panels
• Protected against aging, weather and wear

Central control unit

• Ergonomic and robust design
• High visibility alphanumeric display and programming keyboard
• Made of advanced plastics or stainless steel and anti-vandalism construction (option)
• Access to the front panel protected by hardware key and two levels of passwords

Alarm signalling

• Visual signals: Multi-zone display bar for “height on person” localization; 2 light bars with selectable entry/exit and pacing indication; Green and red metering signals proportional to the mass of the detected target
• Audio signals: 10 selectable continuous and pulsed tones; 10 selectable sound intensities ranging from 0 to 90 dbA at 1m

Type of signalling

• Visual: Fixed or proportional to the mass in transit – visible from 6m under lighting of 4000lux.
• Visual zone indication: 2, 4, 8 or 20 independent zones selectable

Programming

• Remote via RS-232, Infrared Remote Control Unit or Ethernet 10/100 base T interface
• Security level: International Standard (IS) command
• Local by Control Unit alphanumeric display and keyboard
• Programming access protected by user and super-user passwords

Operational features

• Quick reset time as short as 0.2 seconds for high throughput rate
• Very high detection speed (up to 50 ft/sec.)
• One-touch key reading of inbound, outbound and Security Level Data
