Fingerprint Access Control and Time Attendance Model: F18

  • TFT Color Screen
  • Audio-visual indication for acceptance and rejection of valid/invalid fingerprints.
  • 1.2GHz CPU further speeds up processing time
  • Wiegand input & output.
  • Network interface by TCP/IP or RS485
  • Streamlined and slim design for narrow spaces.
  • Anti-passback. Webserver.
  • Access control interface for 3rd party electric lock, door sensor, exit button, alarm and doorbell
  • supports flexible user privilege setting for multi-level management
Add to quote
Add to Wishlist
Add to Wishlist
Share
Categories,

    F18 is an innovative biometric fingerprint reader for access control application. With high-performance firmware functions and compact design, it has become one of ZKTeco’s most popular devices. It is applied with ZKTeco’s latest firmware with user-friendly UI and flexible user privilege settings for multi-level management. The new hardware platform uses ZMM210 core-board with 1.2Ghz CPU. With optimization of both hardware platform and firmware, the new f18 is able to verify fingerprints with even higher efficiency. The device offers flexibility of both standalone installation and installation with any third-party access control panels which support standard Wiegand signal. TCP/IP and RS485 are also available which enable F18 to be applied in different network.

    Weight 23 kg
    Dimensions 12 × 24 × 35 cm
    Size

    Large, Medium, Small

    Function

    TFT Color Screen

    Audio-visual indication for acceptance and rejection of valid/invalid fingerprints.

    More simple and convenient operation.

    Slim and Elegant Design

    Streamlined and slim design for narrow spaces.

    New Platform

    ZMM210 hardware with 1.2GHz CPU further speeds up processing time

    Full Access Control Features

    Anti-passback. Webserver. Access control interface for 3rd party electric lock, door sensor, exit button, alarm and doorbell

    Easy Installation and Connectivity

    Wiegand input & output.

    Network interface by TCP/IP or RS485

    New Firmware

    Adopts new firmware which optimizes various functions and supports flexible user privilege setting for multi-level management

    Specifications

    Technical Specifications

    Fingerprint Capacity

    3000 Templates
    Card Capacity 5,000 (Optional)

    Transaction Capacity

    30,000 Transactions

    Sensor

    ZK Optical Sensor

    Algorithm Version

    ZK Finger VX9.0&10.0

    Communication

    RS232/485, TCP/IP, USB-host

    Access Control Interface

    3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell

    Wiegand Signal

    Input and Output

    Display

    TFT LCD Color Screen

    Interface Styles

    Common, Matrix and Magic styles

    Standard Function

    Webserver, Anti-passback

    Optional Function

    ID Card, Mifare Card

    Power Supply

    12V DC,3A

    Operating Temperature

    0 °C- 45 °C

    Operating Humidity

    20%-80%

    Dimension(WxDxH)

    80×183×42mm
