MultiBio 700 is a new generation multiple biometric identification product. Integrating with Face, Fingerprint and PIN recognition and optional with RFID mode. It performs up to 20 verification methods all in a single device conveniently. MultiBio700 stores 1500 faces and 2000 fingerprint templates and identifies users by 1:N mode. When users glance into the MutiBio700 camera, it captures the relative position, size, and shape of user’s eyes, nose, cheekbones, and jaw features. These parameters are used to create a biometric template which is then used to
subsequently verify or identify each user. MultiBio700 can be used as a standalone access control reader by connecting a door lock, exit switch, alarm and door sensor to the relay contacts. The Wiegand IN and OUT ports can be used to connect 3rd party access control panels and peripherals. The MultiBio700 also includes a USB port for offline data backup/management.
Specifications
Specifications
Display: 3-inch Touch Screen
Face Capacity: 1,500 (1:N)
Fingerprint Capacity: 2,000
ID Card Capacity(optional): 10,000
Log Capacity: 100,000
Camera: High Resolution Infrared Camera
Sensor: ZK Optical Sensor
Communication: TCP/IP, RS232/485, USB-host
Access Control Interface: For 3rd party electric lock, door sensor, exit button, alarm, wired doorbell
Anti-pass back Function: Yes
Wiegand Signal: Input & Output
Standard Access Control Function: Time Zone, Group, Multi-identification Duress mode, Anti-passback, Tamper alarm
Optional Functions: ID Card, Mifare Card
Power Supply: 12V DC
Operating Temperature: 0 – 45 °C
Operating Humidity: 20% -80%
Dimension(L×H×D)mm: 209.4×87.5×91.6
Gross Weight: 0.87kg
